JORDAHL® Anchor Channel JTA W (Hot-Rolled)

    The hot-rolled anchor channels JTA W together with the appropriate JORDAHL® T-head bolts and JORDAHL® accessories create a versatile and proven connection system. They are cast into concrete and transfer high loads reliably in reinforced and non-reinforced concrete structural components and absorb tensile and transverse pull loads at right angles to the axis of the channel.

    Material

    With effective corrosion protection. Available in hot-dip galvanised steel or stainless steel (A4). Standard filling of polyethylene (PE) or polystyrene (PS).

    Load Groups

    Available in five different types of cross-section. Can be delivered in any length up to 19' 7''. Static load-bearing capacity up to 11,575 lbs service load (16,230 lbs design resistance).

    Solutions

    Assembly Instruction

    Advantages

    • Quick, efficient and versatile fastening of high loads
    • Simple compensation of building tolerances
    • No damage to the components by drilling
    • Reduced construction time by using simple hand tools
    • Small edge spacings possible
    • Simple, individual options for application and reusability of the fastening
    • Resistant to fatigue, seismic activities, explosions
    • Optimized geometry with strengthened channel lips for high tightening torques
    • Approved for installation in components with fire safety requirements
